Royal New Zealand Air Force HF Frequencies

RNZAF Air Operations Communication Centre Auckland (AOCCAK)

The AOCCAK is a HF radio network providing communications services for the RNZAF, RAAF, and allied aircraft. In addition, visiting military aircraft may use either the ADF or RNZAF's system when contact with Australian / New Zealand based military authorities is required. Neither system provides a civil or military air traffic control service.

AOCC Auckland is located at RNZAF Whenuapai (S36.47 E174.37) and provides up to 4 General Purpose Network (GPN) frequencies at any one time.

DIAL FREQUENCY Normal Hours of Operation (z) When 24HR Operations (z)
3032 KHz 0900-1000
1900-2100		 0900 - 2100
5687 KHz 1900-1000 CONTINUOUS
8974 KHz 1900-1000 CONTINUOUS
11235 KHz 1900-1000 CONTINUOUS
13206 KHz 2100-0900 2100 - 0900

  • Emission: 2K80J9W

  • Discrete frequencies are available and allocated after initial contact on the GPN

  • Telephone patch facilities are available

  • SELCAL available

  • Hours of operation: AOCCAK 1900 Z - 1000 Z

  • Mode of operation: USB

  • Callsign: AIR FORCE AUCKLAND



Aero Off-Route Frequencies (Military Use):

3 MHz

5 MHz

6 MHz

9 MHz

11 MHz

13 MHz

15 MHz

18 - 30 MHz

3023 (SAR)

4703

6694

8965

10275 (NANDI LINK)

13204

15016

17416  (NANDI LINK)

3032

4709

6700

8968

11178

13206

15025

17542 (NANDI LINK)

3035

4718

6706

8974

11181

13212

15046

17979

3038

4730

6709

8975

11217

13215

15052

17982

3044

4736

6715

8983

11226

13221

15055

17991

3050

4745

6721

8989

11229

13224

15076

17994

3053

4940

6724

8992

11235

13236

15082

18000

3059

5680 (SAR)

6730

9001

11238

13242

15085

18003

3080

5687

6739

9010

11244

13245

15650

18009

3092

5693

6745

9016

11247

13251

15650 (NANDI LINK)

18012

3095

5696

6751

9022

11508

13254

15690 (AUS LINK)

18679 (S/PAC)

3116

5708

6754

9025

12060 (FIJI LINK)

13364

19250 (FIJI LINK)

3122

5711

6760

12081

13417 (NANDI LINK)

19982

3128

5714

7855 (AUS LINK)

12202 (NANDI LINK)

19985

3131

5717

12205 (NANDI LINK)

23210

3152

5726

23215

3948

23265

3960

23297

3963

23300

4059 (AUS LINK)

27535

4095 (AUS LINK)

27991 (S/PAC)

Kiapara Air Weapons Range 2045 KHz J3E - Used by 5 SQN.


RNZAF Operational Squadrons

No.3 Sqn   - RNZAF Base Ohakea - Rotary Wing - Agusta A109LUH (8) & NH90 (Callsign Warrior)(9)
No.5 Sqn   - RNZAF Base Auckland / Whenuapai - Maritime Patrol Squadron - Orion P3K (6)
No.6 Sqn   - RNZAF Base Auckland / Whenuapai - Naval Aviation - SH-2G Seasprite (5)
No.40 Sqn - RNZAF Base Auckland / Whenuapai - Transport - C130H (5) & Boeing 757-200 (2)



Training Squadrons

No.14 Sqn - To be re-raised 2015 - Beechcraft T-6c Texan II (Will replace CFS Sqn) (Callsign Texan)
No.42 Sqn - RNZAF Base Ohakea - Training - Beech King Air B200 (4)
Central Flying School & Red Checkers Aerobatic Team - RNZAF Base Ohakea - Training - CT-4E Airtrainer (13)



WHENUAPAI V/UHF Frequencies
Frequency Use
108.800 VOR
110.700
111.100
119.100
119.900 TWR
120.500
124.300 AUCKLAND APP
125.700
128.300 ATIS
129.600 AUCKLAND APP
134.500 TWR / CTAF
255.400 TWR
270.600
330.200 ILS
331.700 ILS
363.800
412.275 DEFENCE CH. I35
412.300 DEFENCE CH. I36
412.235 DEFENCE CH. I37
412.350 DEFENCE CH. I38
412.275 DEFENCE CH. I39




OHAKEA V/UHF Frequencies
Frequency Use
109.000 VOR
118.100
119.400
120.400
120.700
122.100 GND
122.700
123.200 APP
125.100 APP
125.700
126.200
127.700
128.500 APP
129.700
134.500 TWR / CTAF
135.000 ATIS
255.400 TWR
258.500 GND
263.400 APP
280.400 ATIS


Last updated 8/1/2013



THE FOLLOWING INFORMATION IS FOR ARCHIVAL USE ONLY
CONTENT IS DERIVED FROM PREVIOUS SYSTEMS AND IS NOT CURRENT

RNZAF HF  | -V/UHF- | -SQN FREQUENCIES- | -CALLSIGNS-


Discretes 6754, 6760, 8965, 9010, 9025, 11178, 11217, 11247, 13212, 13233, 13245, 15044, 15055
SAR 3023, 5680

RTTY 75 Bd 5442, 5710, 9003, 9012, 9024, 13256, 17996, 18004, 18011 (RYRY & Fox Tests)

Others listed 4734, 5146, 5242, 5358, 5361, 5433, 5436, 5695, 5698, 5716, 5729, 5754, 5757, 5874, 5877, 5889, 5910, 5942, 6696, 6708, 6711, 6723, 6732, 6753, 6757, 6762, 6869, 6872, 6879, 6882, 6887, 6919, 8967, 8985, 8994, 9024, 9027, 11219, 11228, 11231, 11248, 13223, 13245, 13247, 13366, 13407, 15046, 15048, 15057, 15084, 15087, 17981, 18002, 18014, 19612, 23214, 23217, 23302 & 23332

 VHF/UHF
Whenuapai AFB (Auckland)
VHF TWR 119.9 & 134.5
ATIS 128.3
PAR 125.7
OPs 135.1NFM
Ground Crews 140.6375, 141.6625
Base OPs 142.075 & 142.275
Police 140.825, 143.475
Fire 143.725, 143.7375
UHF TWR 255.4
PAR 270.6

Ohakea AFB
VHF TWR 119.9 & 134.5
GRND 122.1
PAR 125.7
CNTRL 119.2, 123.3, 126.2, 126.7
APPROACH 125.1
GCI 128.5
OPs 127.9, 135.1
UHF TWR 255.4
GRND 258.5
PAR 270.6
APPROACH 263.4
CNTRL 269.3
GCI 266.5 & 272.4

Squadron freqs
 "Warrior" No3 SQN (UH-1s)
VHF 130.8 & 140.5
UHF 345.7

"Albatross" No5 SQN (P3s)
VHF 140.1
UHF 279.4 & 282.2

 "Kea" No14 SQN (MB339s) - DISBANDED
VHF 126.7, 135.35, 141.1
UHF 279.5 & 321.2

Air to Air Tactical Studs
235.2 Stud 11, 259.2 Stud 12, 262.0 Stud 13, 273.1 Stud 14, 300.4 Stud 15, 303.6 Stud 16, 304.5 Stud 17, 316.7 Stud 18, 316.9 Stud 19, 352.6 Stud 20

"Compass" No40 SQN (B727s, C130s)
VHF 135.4

"Pidgeon" No42 SQN (Beach King B200s)
VHF 135.2

"Tiki" No75 SQN (A-4s) -DISBANDED
VHF 143.0
UHF 303.6 Stud 16, 304.5 Stud 17, 316.7 Stud 18, 316.9 Stud 19 & 321.1

Red Checkers Display Team (CT4s)
VHF 126.3, 131.8, 139.1 & 139.7

Parachute OPs
135.3

Airshows
VHF 135.9

Dept of Defence Bombing Range
UHF 340.2

Aircraft Callsigns
 AMBER A-4s
 BOEING 727s
FALCON MB339s
 HERCULES C130s
JADE A-4s
 IROQUOIS UH-1s
KIWI various A/C operating internationally
KING Beach King B200s
MACCHI MB339s
 ORION P3s
RED A-4s
SKYHAWK A-4s
SIOUX B47G-3B-1s



..
